ARE YOU LOOKING FOR BUILDING PERMIT DRAWINGS?

 Whether you're planning a new deck, a home addition, or a basement suite renovation, most projects require a building permit—and that starts with the right plans. At EngineeredPlans, we specialize in creating the floor plans and architectural drawings you need to move forward. We don’t just draft—we ensure your plans meet building code requirements so your project gets approved quickly and built right.


We specialize in preparing permits for the following types of projects:

  • Custom Build Homes
  • Secondary Dwelling Permit
  • Laneway and Garden Suite Permits
  • Interior Renovation Permit
  • Deck Building Permit
  • New addition to an existing home
  • Garage Conversion Permit
  • Exterior Home Renovation Permit


 Call us today at (437) 808 7039 or email us at info@engineeredplans.ca for a free consultation


Home addition building permit drawings

 We offer a package to design and get you project approved by the city of Toronto. The team here at EngineeredPlans is comprised of Architects and Engineers who will provide expert opinion and guidance on your unique project. We offer competitive pricing compared to our competitors due to our years of experience in the renovation industry and a skilled team. We have successfully completed 100’s of projects around the GTA.


We offer the following services in the Residential space:

  • Deck drawings
  • Second-floor permit
  • First-floor additions permits
  • Attic home additions
  • Multi-story home additions permits
  • Home additions permits
  • Multi-story home additions
  • Interior additions permits
  • Kitchen extensions permits
  • Garage conversions permits
  • Underground additions permits
  • Outdoor living space permits
  • Rear extensions permits
  • Laneway suites permits
  • Multi-unit construction permits
  • Exterior additions permits



Building Permit Drawing

Secondary Dwelling building Permits

You may want to finish your basement for yourself or turn it into a legal secondary dwelling. We provide one worry free package that will help you get your secondary dwelling building permit.

For any of these changes, you will need to start with a free home inspection in Toronto. This will give everyone a better idea of what the scope of the project will be and what type of drawings and services will be required.

We look for the following things when we visit.

  • Existing natural and artificial lighting
  • Means of egress and entrance to the secondary dwelling
  • Locations of bedrooms, kitchen and washrooms.
  • Minimum areas as required by OBC.
  • New plumbing / HVAC / Mechanical


Find more details regarding Secondary Dwelling requirements here.

Find out more

Toronto basement Building permit
basement walkout Engineers in Toronto
engineering firms Toronto

Basement Renovation building Permit

Basement Renovations is the easiest way to add living space to your existing home.  Interior renovations need building permit approved by the city of Toronto. We provide one worry free package that includes everything from onsite measurements to permit application. Reach out today to find out how we can help you.


Deck building permit

We have prepared 100's of deck designs and deck building permits around the GTA. We have previously done floating decks, 2nd story decks and Porch designs.



We offer variety of deck designs and permit plans for your projects. Many of the deck plans include features to make your deck unique including canopies, pergolas and planter boxes. Our plans include a framing plan, front & side elevations, footing layout, 3D rendering cover sheet, material list and a typical detail building guide.

Find out more

canopy Building permit
deck design Engineers in Toronto
engineering firms Toronto

Canopy and Pergola designs building permit designs

Building any kind of deck or patio, with or without a gazebo or pergola requires a building permit from the city of Toronto. You may have a design in mind or you may want some guidance. We offer a free home assessment and consultation. This will give everyone a better idea of what the scope of the project will be and what type of drawings and services will be required.



Once the initial home assessment is done and we have taken all the necessary measurements and 3d scans will prepare a set of drawings for a permit application. This set includes a site plan, floor plans (architectural and structural), elevations, and details as required by the scope of your project.


We offer the following services in the Residential space:

  • Porches
  • Pergolas
  • Gazebos


Find out more

INterior Renovation building permits

EngineeredPlans, located in Toronto, is glad to assist you in evaluating your renovation plans and construction permit drawings. We work with client and contractors to eliminate unnecessary delays. Our designs strictly adhere to municipal and city of Toronto requirements, ensuring compliance with Ontario Building Code 2020. We streamline the entire renovation process by meticulously preparing and submitting all essential drawings, drafts, and documentation to your city.


Every drawing from EngineeredPlans is meticulously crafted to meet building codes and align with municipal zoning regulations.

Our interior renovations permit drawings encompass a comprehensive package, including a site plan, floor plans, elevations, and all project-specific details.

With over a decade of experience, we bring expertise and proficiency to every project.

We prioritize adherence to health and safety standards in all our undertakings.

Our drawings bear the stamp of approval from an Engineer and/or a BCIN professional, tailored to meet the specific requirements of each project.




Client Reviews


Recent Work

Home addition Building permit
Engineers in Toronto
Engineering firms Toronto

Richmond HIll Basement Renovation

We provided engineering and design services for a basement walkout.

Learn More
secondary dwelling Building permit
Engineers in Toronto
engineering firms Toronto

Richmond Hill – Secondary Dwelling Residence

We provided engineering and design services for a basement walkout.

Learn More
secondary dwelling Building permit
Engineers in Toronto
engineering firms Toronto

VAughan Secondary Dwelling

We provided engineering and design services for a basement walkout.

Learn More
secondary dwelling Building permit
Engineers in Toronto
engineering firms Toronto

Crossgate – Secondary Dwelling Residence

Scope of Work: Permit Drawings for Secondary Dwelling Basement Apartment

Client: Ahmed

Location: Ottawa, ON

Learn More
secondary dwelling Building permit
Engineers in Toronto
engineering firms Toronto

Willowmere Way – Secondary Dwelling Residence

Scope of Work: Permit Drawings for Secondary Dwelling Basement Apartment

Client: Harpreet

Location: Willowmere Way, Gloucester

Learn More
secondary dwelling Building permit
Engineers in Toronto
engineering firms Toronto

Basement Rental Unit ConversioN - Mississauga, ON

We provided engineering and design services to renovate an existing unfinished basement unit.

Learn More
secondary dwelling Building permit
Engineers in Toronto
engineering firms Toronto

existing finished basement legalization

We provided engineering and design services to legalize an existing basement.


Contact Us

Contact US

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

Better yet, see us in person!

We love our customers, so feel free to visit during normal business hours.

Engineered Plans

65 Times Avenue, Thornhill, Ontario L3T 7T6, Canada

Contact: 437 808 7039 Email: info@EngineeredPlans.ca


WHEN IS A BUILDING PERMIT TYPICALLY REQUIRED?

  1. When you construct an accessory structure larger than 10 square metres* (108 square feet) in area, such as

  • Detached Garage
  • Workshop
  • Garden shed
  • Carport
  • Pool house or cabana

 2. Finishing a basement, if the work proposed includes any of the following:

  • Structural or material alterations
  • Installing or modifying heating and or plumbing systems
  • Excavating and/or constructing foundations
  • Basement underpinning
  • Constructing a basement entrance
  • Adding a second suite
  • Energy and environmental building improvements, such as
  • Roof top storm water retention systems
  • Green roofs
  • Structures used in the support of a wind turbine generator with a rated output of more than 3kW
  • Solar projects such as installation of solar collector systems and solar hot water systems

3.  Construct a deck more than 60 centimetres (24 inches) above ground

4.  Construct a retaining wall more than one metre (3 feet 3 inches) in height provided the retaining wall is on or adjacent to public property (including streets), building entrances, and on private property accessible to the public

5.  Change a building’s use (i.e. from residential to office or single dwelling unit house to multi-dwelling unit house). Even if no construction is proposed, if a change of use is proposed a building permit is required

Building permit process

Learn more about the Building permit process in Ontario and some the different services that we offer.

Learn More

What do we offer

BUILDING DESIGN

BUILDING PERMITS

BUILDING PERMITS

  • Home Addition Permits
  • Interior Alteration Permits
  • Basement Walk-out Permits
  • Secondary Unit Basement Permits
  • Decks/ Landscaping Permits
  • Detached/Attached Garage Addition
  • Laneway Suite Permits
  • Sunroom Permits
  • Load Bearing Wall Removal Permits

BUILDING PERMITS

BUILDING PERMITS

BUILDING PERMITS

  • Garden Suites
  • Custom home permits
  • Residential additions
  • Attached/detached garages and carports
  • Interior alterations
  • Load bearing wall(s) removal
  • Decks, porches, verandas

OTHER SERVICES

BUILDING PERMITS

OTHER SERVICES

  • As Built Drawings
  • Marketing Drawings
  • Drafting Services (2D/3D)
  • Smart home Planning
  • 3D Renderings
  • Site Plan Drawing

Service Areas

How does the process work?

OTHER SERVICES

  • Toronto
  • Mississauga
  • Vaughan
  • Brampton
  • Markham
  • Newmarket
  • Oakville
  • Oshawa
  • Richmond Hill
  • Ajax
  • North York

How does the process work?

How does the process work?

How does the process work?

1. Contact Us

2. Gather required information

3. Receive Quote

4. Recieve Permit Drawings


Downloads

SAMPLE Ottawa Secondary Dwelling (pdf)

Download

SAMPLE - GARDEN SUITES (pdf)

Download

SAMPLE - Home Addition - 1 (pdf)

Download

SAMPLE - Home Renovation - 1 (pdf)

Download

SAMPLE - Gazebo - 1 (pdf)

Download

Engineering Consulting Services

Comprehensive guideline on getting your building permit in toronto

Our Mechanical Engineering services provide innovative solutions for your product design, development, and manufacturing needs. Our team of experts has extensive experience in creating designs that meet the highest standards of quality and safety.

STEP 1: REVIEW YOUR PROPERTIES ZONING TO DETERMINE WHAT IS POSSIBLE

 There is an abundance of information available online regarding the zoning bylaws applicable to properties in the City of Toronto. A crucial tool to be aware of is the Toronto Interactive Zoning Bylaw Map, which allows you to identify your property's zoning and understand the specific regulations it is subject to. If navigating the map seems overwhelming, any reputable General Contractor or permit designer/architect should be able to provide you with information on what is feasible, what is not, and potential options for your property (further details on the latter are discussed below).


If you determine your property is or might-be able to complete the work you want to complete, then you can proceed to step 2.

STEP 2: DESIGNER SELECTION AND PRELIMINARY COST ESTIMATES

 Once you have a preliminary understanding of the feasible options for your property, it's time to solicit fee proposals from permit designers and/or architects. These proposals will provide pricing details for the creation of necessary drawings that must undergo City of Toronto review for the issuance of your building permit. To assist you in making an informed decision, we've compiled a comprehensive guide outlining key considerations when selecting a permit designer or architect for your residential construction permit.

Simultaneously, at this stage, it is advisable to engage with a General Contractor experienced in similar residential construction projects. They can assess your proposed project and furnish a preliminary cost estimate. This step ensures that you can assess the financial feasibility of the project before finalizing your choice of designer or architect. Notably, when working with BVM Contracting, this service is offered at no additional cost and is a standard part of our procedure for anyone considering collaboration with us.

Pro Tip: Emphasize the importance of having your permit designer or architect provide a detailed breakdown of permit fees. This information will enable you to budget effectively for the overall cost of obtaining your permit.

STEP 3: PRELIMINARY PLANS AND ZONING REVIEW

Once you've confirmed the financial viability of your intended renovation or home building project and have committed to a permit designer or architect, the next phase involves actively developing plans for your proposed work.

The specific process may vary based on your chosen project, but the ultimate objective remains consistent – to compile a comprehensive application for your project, ready for the City of Toronto Building Department's assessment for compliance with local zoning by-laws and exceptions. It's important to note that fees for the zoning review (25%) are applicable, but these contribute toward the total permit cost, with no additional charge for this specific review.

Emphasizing the significance of submitting your preliminary set of drawings promptly for zoning review is crucial. This step is instrumental in determining your subsequent actions (as outlined below), and timely submission is vital for obtaining the necessary feedback. The duration of this phase typically ranges from 2 to 4 months, contingent on factors such as effective collaboration with your designer, responsiveness to requested plan changes, the need for an updated property survey to support the application, and the speed at which the City provides feedback on your proposed plans.

STEP 4A: RECEIPT OF ZONING CERTIFICATE AND PERMIT SUBMISSION DRAWINGS

If your zoning application for your proposed project aligns with all local Toronto zoning by-laws, you will receive a Zoning Applicable Law Certificate, confirming the eligibility of your application for submission of a building permit.


Upon obtaining the certificate, your permit designer or architect will proceed to incorporate the necessary building code information pertinent to your proposed project. This prepares the plans for a subsequent review by the City, focusing on their building code examination.

In addition to the work carried out by the permit designer or architect, your project will likely undergo scrutiny by a structural engineer to undertake the engineering design required for the proposed endeavor.

If you are constructing a new home, ancillary structure, or home addition, an HVAC permit will be necessary. This entails engaging an HVAC designer or engineer to conduct the essential heat loss calculations and HVAC design. It's worth noting that the HVAC permit is distinct from the building permit, and while it's not obligatory to submit both simultaneously, it is common practice to do so for comprehensive project information. Additionally, the permit designer or architect will initiate a separate application for a plumbing permit.

The creation of Ontario Building Code (OBC) overlay drawings, HVAC design/permitting, and structural design occurs post-approval of the Toronto zoning review and certificate acquisition. Initiating work before this stage poses the risk of having to redo structural and HVAC designs, incurring additional costs.


Compiling the "Building Permit Drawings" typically spans 1 month, with an additional month for the permit issuance once submitted to the City. At this juncture, you will also be required to settle the remaining permit fees for your project. The City of Toronto transparently outlines its building permit fees on their website, emphasizing that non-flat fees are calculated per square meter. It's crucial to be aware of this, as apparent low numbers can be misleading.



STEP 4B: MINOR VARIANCES AND COMMITTEE OF ADJUSTMENT IN TORONTO

If your zoning application has been flagged for minor variances to the local zoning bylaws of your neighborhood, you'll encounter two options:

  1. Make the necessary changes to ensure your project complies.
  2. Submit an application to the Committee of Adjustment to seek approval for the minor variances.

It's essential to note that your permit designer or architect can assist in assessing potential risks associated with the Committee of Adjustment process, gauging the likelihood of obtaining approval. While there is always a risk of rejection, in cases of uncertainty, consulting a private planning consultant is an option, and we can provide referrals if needed.

If you choose to go to the Committee of Adjustment, anticipate the following:

  • Additional costs for submitting the application and being represented by your permit designer, architect, or planning consultant (recommended for 99% of applications).
  • Additional waiting time for a Committee of Adjustment hearing, which can range from 2 to 6 months.
  • Community involvement, as neighbors can submit letters of support or opposition, potentially expressing their views during the hearing. Securing neighbor support is crucial, especially for more complex applications.

Once your Committee of Adjustment Hearing is scheduled, conducted, and approval is obtained, you can return to step 4A to complete your permit application. In case of rejection, proceed to step 5.

It's worth noting that the Committee of Adjustment may grant partial approval with conditions, requiring changes or concessions to your plans to conform to specific minor variances. While this allows you to move forward to the permit submission phase, adjustments will be needed. If the Committee of Adjustment presents this option, it's advisable to consider it, as proceeding to step 5 involves additional costs and more time.




Frequently Asked Questions

Please reach us at  if you cannot find an answer to your question.

Building permits are typically needed for construction, demolition, renovation, and additions to residential, commercial, and industrial properties. Projects involving changes to a building’s structure, plumbing, or mechanical systems often require permits


The timeline for obtaining a building permit depends on the complexity of your project and the workload of the city’s building department. Simple projects may be approved in a few weeks, while more complex projects can take several months.


The FASTRACK building Building permit service aims to issue permits for specific home renovation projects within a 5-business-day timeframe. However, it's important to note that FASTRACK applications are designed for minor interior renovations and projects without any external work. For more extensive projects like additions, garages, or new builds, the processing time is typically longer, depending on the project's individual scope.


It's often overlooked that the city of Toronto involves different departments in reviewing various aspects of an application. Different departments handle HVAC, life safety, and structural drawings. If your project involves external work, such as building an addition or a shed, the city of Toronto will also review it to ensure compliance with zoning by-laws. Obtaining a Building permit entails more than just submitting a few documents, which is why the process generally extends beyond the 5-day period.




We've encountered numerous clients facing similar issues. They acquire a property only to discover that the second-floor addition, deck, or secondary unit was not constructed in compliance with building codes and was erected unlawfully. The harsh reality is that, if you've purchased such a property, it now falls upon you to rectify the mistakes of the previous owners, despite them being the ones who implemented the changes. This is why conducting a thorough inspection before purchasing the home is crucial, ensuring that everything is in proper order.



 There are several stages to obtaining a building permit and completing construction:

  • First, you need to gather all the building paperwork that allows you to start the process.
  • Then you need to submit your drawing to the city of Toronto building permit department and wait for them to review your application and give you the building permit.
  • Upon completion of every construction stage, an inspector will visit the site and determine whether the construction can go on and at the end they will provide you with the final occupancy approval.


According to legal obligations, sellers are required to disclose any additions or unpermitted work they are aware of. However, openly addressing this situation allows for collaboration with buyers, reassuring them that necessary adjustments can be undertaken. Selling a house with minor unpermitted work is indeed a viable possibility.


We recommend reaching out to us for a free consultation to determine if you home has any ongoing permits that need to be closed.


The rules and regulations regarding building without a Building permit vary by municipality in Ontario, and it's important to check with your local municipal building department for specific guidelines.

Constructing a backyard shed, garden shed, or storage shed does not necessitate a building permit if it is smaller than 160 square feet (or 15 square meters). However, any shed exceeding 160 square feet does require a building permit. It's important to note that building permits are obligatory for accessory structures with plumbing, irrespective of their size. For additional details, you can refer to the Toronto website.


In Ontario, it is illegal to build or renovate a building without the required permits. The legislative guidelines for constructing or renovating structures in the province are provided by the Building Code Act of Ontario. Without a valid permission, it is illegal to construct, dismantle, or permit the construction or demolition of a building. If these actions are carried out without the required authorization, there may be severe repercussions, such as fines, penalties, and possible legal action.

If found guilty of a breach of the 1992 Building Code Act, such as building without a permit, the fines might reach $100,000 for many infractions and $50,000 for first offenses.


See our detailed guide here.



Pre-Application Consultation:

  • Before starting the application process, it's advisable to have a pre-application consultation with EngineeredPlans. This allows you to discuss your project, understand local regulations, and receive guidance on the Building permit application process.

Prepare Your Plans:

  • Create detailed plans and drawings of your proposed construction project. These should include architectural, structural, mechanical, and electrical details that meet Toronto Permit Office Requirements. The level of detail required may vary based on the complexity of the project.

Complete Application Forms:

  • Fill out the necessary building Building permit application forms from City of Toronto provided by your local municipality. Include all required documentation, such as site plans, floor plans, elevations, and any other relevant information. Be sure to provide accurate and complete details to avoid delays.

Submit Application:

  • Submit the completed application forms and supporting documents to the Toronto Building permit department. There is typically a submission fee, which varies depending on the municipality and the scope of the project.

Application Review:

  • The building permit department will review your application to ensure it complies with local zoning by-laws, building codes, Toronto and Region Conservation Authority (TRCA) and other regulations. This process may involve multiple departments, such as planning, engineering, and fire services.

Issuance of Permit:

  • Once your application is approved, the building department will issue the building permit. This document grants you legal permission to begin construction. It will outline specific conditions and requirements that must be followed during the construction process.

Commence Construction:

  • With the building Building permit in hand, you can start the construction process. It's essential to adhere to the approved plans and any conditions specified in the permit.

Inspections:

  • Throughout the construction process, inspections may be required at various stages. Contact the building department to schedule inspections to ensure that the work complies with the approved plans and building codes.

Final Inspection and Occupancy:

  • Once construction is complete, a final inspection is typically required. If the work meets all the necessary standards, a Certificate of Occupancy or a similar document may be issued, allowing you to occupy or use the structure.


1. Constructing a new structure, apartment, etc.

2. Expand a pre-existing structure.

3. Make changes to the structure.

4. Build an auxiliary structure larger than ten meters.

5. Construct a deck.

6. If the retaining wall is on or near to public land, construct a wall that is higher than one meter.

7. Demolish a building entirely or in part.

8. Construct a tent if it spans more than 60 square meters, is affixed to a building, or is located no more than 9 meters from another structure.

9. Install a wood-burning stove or fireplace

10. Set up the chimney.


Copyright © 2022 Engineered Plans - All Rights Reserved.

Powered by

  • Toronto Permit Drawings
  • Toronto Basements
  • Basement Permit Process
  • Building Permit Process
  • Dundas – Renovation of
  • Richmond Hill Permit
  • Valleymede Drive
  • Vaughan Permit
  • Ottawa Secondary Dwelling
  • Willomere

This website uses cookies.

We use cookies to analyze website traffic and optimize your website experience. By accepting our use of cookies, your data will be aggregated with all other user data.

Accept
